Specifications
- - RoHS
- - Meets C3 Standards
- - Jack Insertion Cycle: Over 2000 Cycles
- - Plug Tensillity: 18 lbs
- - Operation Temperature: -40 ~ +70 Degree Celsius
- - Body: Fireproof ABS UL-94V0
- - PCB: FR-4 / UL-94V0
- - Jack: 8P8C 6 micro inches gold plated
- - IDC Body: Fireproof ABS UL-94V0
- - IDC Pin: Bronze & Tinned
- - Plug: 8P8C 50 micro inches gold plated/UL94V-2
- - Cable: Copper/PVC
- - Boot: PVC
- - Insulation Resistance: 500M ohms (min.)
- - Contact Resistance: 20m ohms (max.)
- - Current Rating: 1.5 Amps.
- - DC Resistance: 0.1 ohms (max.)
- - Withstanding Volatage: 1000 VAC RMS @ 60Hz/1min.
